ARGON 18 - E117 - SRAM Force AXS
New
7-10 days
ARGON 18 - E117 - SRAM Force AXS
9,245.00€
Race-ready aero for triathlon and time trial.
The Argon 18 E117 Ultegra Di2 blends high-performance carbon aerodynamics with electronic shifting to deliver a machine built for speed and precision. From the integrated cockpit to the aero-optimized frame, it’s crafted for athletes who demand top-level results.
SRAM Force AXS Components
Argon 18 Integrated Brake System
Argon 18's integrated brakes seamlessly merge aerodynamics with braking efficiency. Designed to reduce drag and enhance performance, the brakes are integrated into the frame, providing precise control and unparalleled aerodynamic advantage.
SRAM Force AXS Powermeter 48/35
All performance, no compromises. Force AXS wins with fully wireless technology, refined ergonomics, and further AXS integration. This pro-level, lightweight drivetrain offers reliable power output data, effortless braking and faster front shifting, so you can focus on performing your best on the road.
Scope R6.A
The Scope R6.A channels the racing pedigree of the Artech 6.A into a wheelset built for pure speed and control. Featuring a deep 65mm aerodynamic profile and tuned for an ultra-responsive ride feel.
51 Speedshop Custom Extensions
Featuring an airfoil shape that hugs the arms to optimize aerodynamic performance, 51 Speedshop extensions also offer a 30 degree grip angle to provide neutral wrist orientation, promoting upper body comfort.
Frameset
Frame
E117
Fork
E117
Headset
E117
Integrated Cables
Yes
Wheels
Wheels
Scope R6.A
Tires
Vittoria Corsa N.EXT TLR 29c
Tire Clearance
30C (32mm)
Group
Bottom Bracket
SRAM DUB PF 86.5 Road
Front Derailleur
SRAM Force AXS E1
Rear Derailleur
SRAM Force AXS E1
Crankset
SRAM Force AXS Powermeter 48/35
Chain
SRAM CN Force E1
Cassette
SRAM CS XG 1270 E1 10-33
Brakes
Brakes
Argon 18 Integrated Brake System
Brake Levers
Argon 18 Integrated Brake System
Rotors
TRP TR140-25 / F:140mm R:140mm
Shifters
SRAM Wireless blips
Other Components
Handlebar
Argon 18 Integrated Cockpit
Stem
Argon 18 Integrated Cockpit
Bar Tape
Prologo Plaintouch black
Saddle
ISM PR1.0
Seatpost
Argon 18 E117 specific
Extensions
51 Speedshop Custom Extensions
Included with bike
Toolkit
Yes
Geometry and fit
Geometry
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
A
Seat tube Height
cm
45,5
50,0
51,6
54,2
56,8
B
Seat tube angle
deg
78,0
78,0
78,0
78,0
78,0
C
Head Tube Angle
deg
72,0
72,0
72,0
72,0
72,0
D
Top tube length
cm
49,2
50,4
51,7
52,7
54,5
E
Chain stay length
cm
41,3
41,3
41,3
41,3
41,3
F
Wheelbase
cm
97,6
98,9
100,4
101,7
103,8
G
BB Drop
cm
7,0
7,0
7,0
7,0
7,0
H1
Head Tube Length 3D (0mm)
cm
4,9
6,0
7,7
10,4
13,1
H2
Head Tube Length 3D (35mm)
cm
8,4
9,5
11,2
13,9
16,6
I
Stand Over Height
cm
72,9
76,7
78,2
80,8
83,3
L
Fork Length (Axle-to-crown)
cm
37,5
37,5
37,5
37,5
37,5
R
Fork Rake
cm
4,5
4,5
4,5
4,5
4,5
Fit (Stack and Reach)
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
J
Armpad stack
cm
55 - 67,4
56 - 68,4
57,6 - 70
60,2 - 72,6
62,8 - 75,1
K
Armpad Reach
cm
40,5 - 50,4
41,5 - 51,4
42,5 - 52,3
43 - 52,8
44,2 - 54,1
Saddle Height Min
cm
60.0
64,5
66,1
68,7
71,3
Saddle Height Max
cm
77.0
81,5
83,1
85,7
88,3
