ARGON 18 - SUM PRO - SRAM Force AXS
Ettetellimisel
ARGON 18 - SUM PRO - SRAM Force AXS
9 995,00€
Paista silma Sum Pro vapustava disainiga, millel on rafineeritud esteetika ja esmaklassiline konstruktsioon, mis muudab iga sõidu erakordseks.
SRAM Force AXS Components
Frameset
Frame
SUM Pro
Fork
SUM Pro specific
Headset
FSA Headset NO.55R 1.5'' + 3D
Integrated Cables
Yes
Wheels
Wheels
Zipp 404 Firecrest
Tires
Vittoria Corsa PRO 28-622 TLR, para-black G2.0
Tire Clearance
30C (32mm)
Group
Bottom Bracket
CeramicSpeed BB86 DUB Coated
Front Derailleur
SRAM Force AXS
Rear Derailleur
SRAM Force AXS
Crankset
SRAM Force AXS Powermeter 48/35
Chain
SRAM FORCE 12S
Cassette
SRAM XG 1270 10-33 XDR
Brakes
Brakes
SRAM Force AXS
Brake Levers
SRAM Force AXS
Rotors
SRAM Centerlock Paceline X / F:160mm R:140mm
Shifters
SRAM Force AXS
Other Components
Handlebar
Vision Metron 5D ACR EVO
Bar Tape
Ciclovation LEATHER TOUCH Tornado Gloss
Saddle
Repente Quasar CR Carbon Rail
Seatpost
SUM specific (included with frameset)
Geometry and fit
Geometry
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
A
Seat tube Height
cm
39.5
42.5
46.0
50.5
55.0
59.5
B
Seat tube angle
deg
75.0
74.5
74.0
73.5
73.0
72.5
C
Head Tube Angle
deg
71.2
72.1
72.7
72.7
72.7
73.0
D
Top tube length
cm
50.3
52.0
53.8
55.7
57.8
60.0
E
Chain stay length
cm
41.0
41.0
41.0
41.0
41.0
41.0
F
Wheelbase
cm
96.7
97.2
97.5
99.0
100.6
102.0
G
BB Drop
cm
6.9
7.3
7.7
7.7
7.7
7.7
H1
Head Tube Length 3D (0mm)
cm
6.9
8.5
10.1
12.6
15.2
18.0
H2
Head Tube Length 3D (15mm)
cm
8.4
10.0
11.6
14.1
16.7
19.5
H3
Head Tube Length 3D (25mm)
cm
9.4
11.0
12.6
15.1
17.7
20.5
I
Stand Over Height
cm
67.6
70.0
72.7
76.6
80.4
84.1
Fit (Stack and Reach)
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
J
Stack 3D (0mm)
cm
47.1
49.3
51.6
54.0
56.5
59.2
J
Stack 3D (15mm)
cm
48.5
50.7
53.0
55.4
57.9
60.6
J
Stack 3D (25mm)
cm
49.5
51.7
54.0
56.4
58.9
61.6
K
Reach 3D (0mm)
cm
37.5
38.2
38.9
39.7
40.5
41.4
K
Reach 3D (15mm)
cm
37.0
37.7
38.5
39.3
40.1
41.0
K
Reach 3D (25mm)
cm
36.7
37.4
38.2
39.0
39.8
40.7
Saddle Height Min
cm
56.5
59.5
63.0
67.5
72.0
76.5
Saddle Height Max
cm
71.5
74.5
78.0
82.5
87.0
91.5
