ARGON 18 - SUM PRO - Shimano Dura-Ace Di2
Order in advance
ARGON 18 - SUM PRO - Shimano Dura-Ace Di2
12,500.00€
Stand out with the stunning design of the Sum Pro with refined aesthetic and premium builds, making every ride extraordinary.
Shimano Dura-Ace Di2 Components
Frameset
Frame
SUM Pro
Fork
SUM Pro specific
Headset
FSA Headset NO.55R 1.5'' + 3D
Integrated Cables
Yes
Wheels
Wheels
Scope Artech A4
Tires
Challenge Criterium RS TLR 28c Black
Tire Clearance
30C (32mm)
Group
Bottom Bracket
CeramicSpeed BB86 Shimano Coated
Front Derailleur
Shimano Dura-Ace Di2 R9250
Rear Derailleur
Shimano Dura-Ace Di2 R9250
Crankset
Shimano Dura-Ace R9200 52/36
Chain
Shimano Dura-Ace CN-M9100 12S
Cassette
Shimano Dura Ace CS-R9200 11-30
Brakes
Brakes
Shimano Dura-Ace Di2 R9270
Brake Levers
Shimano Dura-Ace Di2 R9270
Rotors
Shimano Dura-Ace RT-MT900 / F:160mm R:140mm
Shifters
Shimano Dura-Ace Di2 R9270
Other Components
Handlebar
Vision Metron 5D ACR EVO
Bar Tape
Ciclovation LEATHER TOUCH Tornado Gloss
Saddle
Repente Quasar CR Carbon Rail
Seatpost
SUM specific (included with frameset)
Geometry and fit
Geometry
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
A
Seat tube Height
cm
39.5
42.5
46.0
50.5
55.0
59.5
B
Seat tube angle
deg
75.0
74.5
74.0
73.5
73.0
72.5
C
Head Tube Angle
deg
71.2
72.1
72.7
72.7
72.7
73.0
D
Top tube length
cm
50.3
52.0
53.8
55.7
57.8
60.0
E
Chain stay length
cm
41.0
41.0
41.0
41.0
41.0
41.0
F
Wheelbase
cm
96.7
97.2
97.5
99.0
100.6
102.0
G
BB Drop
cm
6.9
7.3
7.7
7.7
7.7
7.7
H1
Head Tube Length 3D (0mm)
cm
6.9
8.5
10.1
12.6
15.2
18.0
H2
Head Tube Length 3D (15mm)
cm
8.4
10.0
11.6
14.1
16.7
19.5
H3
Head Tube Length 3D (25mm)
cm
9.4
11.0
12.6
15.1
17.7
20.5
I
Stand Over Height
cm
67.6
70.0
72.7
76.6
80.4
84.1
Fit (Stack and Reach)
XXS44-46
XS47-50
S51-53
M54-56
L57-59
XL60-62
J
Stack 3D (0mm)
cm
47.1
49.3
51.6
54.0
56.5
59.2
J
Stack 3D (15mm)
cm
48.5
50.7
53.0
55.4
57.9
60.6
J
Stack 3D (25mm)
cm
49.5
51.7
54.0
56.4
58.9
61.6
K
Reach 3D (0mm)
cm
37.5
38.2
38.9
39.7
40.5
41.4
K
Reach 3D (15mm)
cm
37.0
37.7
38.5
39.3
40.1
41.0
K
Reach 3D (25mm)
cm
36.7
37.4
38.2
39.0
39.8
40.7
Saddle Height Min
cm
56.5
59.5
63.0
67.5
72.0
76.5
Saddle Height Max
cm
71.5
74.5
78.0
82.5
87.0
91.5
