BH - LYNX RACE 4.0 DX406

Name: BH - LYNX RACE 4.0 DX406
Brand: BH Bikes
SKU: DX406
Price: 3399.00 EUR
Availability: OutOfStock

New Order in advance

BH - LYNX RACE 4.0 DX406

Stock: Order in advance
Model: BH - LYNX RACE 4.0 DX406
SKU: DX406

BH Bikes

Product Views: 0

Based on 0 reviews. - Write a review

3,399.00€

Available Options

BH bike color

Size

Qty

Add to Cart

Buy Now Ask Question

Add to Wish List Compare this Product

Request more info

This product qualifies for free shipping

Always fast. On short distances. On long distances. On tracks. On trails. Going up. Going down. This is what you want from an XC bike that doubles as a marathon bike. The Nº1 frame for the World Cup with David Valero and BH Coloma Team.

Frame	Frame Lynx Race Carbon, PC Layup,Acros ICR/ Alloy7005 Rear	Rear shock Fox Float Evol Performance, 190x45mm, DCL, DRM, CMF	Fork Fox 32 Rhythm 120mm
Drivetrain	Shift levers Shimano XT 8100 12sp	Rear derailleur Shimano XT 8100 12sp	Crank set Shimano MT510-1 175mm 32T 55mm	Bb set Shimano PF92	Cassete Shimano Deore 6100 10/51	Chain Shimano XT 118L
Brakes	Front brake Shimano MT410 180mm	Rear brake Shimano MT410 160mm
Wheelset	Tires Maxxis Ardent EXO 2.25 F/ Maxxis Ikon EXO 2.25 R	Inner tubes Chaoyang 29x21.10/2.35	Rims Race Face Aeffect 32H 27mm internal	Hubs Shimano MT400/410 32H	Spokes Black Inox 2.0
Seat	Saddle Prologo R4	Seat clamp BH EVO 34,9mm	Seatpost Race Face Aeffect 150mm 31,6mm
Cockpit	Handlebar BH LITE Flat 780mm	Stem BH SL 80mm, 31,8mm, +/-6º	Headset Acros ICR 36/45º, Block Lock 160º	Grips BH SL Lock On

LYNX RACE 4.0

DX406

	SM	MD	LA	XL
H1 - ST LENGTH	400	440	480	520
H2 - HT LENGTH	90	95	110	125
H3 - FORK LENGTH	525	525	525	525
H4 - TT LENGTH	571	580	605	625
H5 - FRONT CENTER	691	715,9	744,8	772,5
H6 - CHAINSTAY LENGHT	430	430	430	430
H7 - WHEEL BASE	1096	1131	151,5	1168
H8 - BB DROP	40	40	40	40
A1 - ST ANGLE	76	76	76	75
A2 - HT ANGLE	68	68	68	68
reach	410	436	456	472
stack	575	580,1	595,2	610,2
